24V Lithium Battery Brushless Motor Electrode Cap Grinder Single Side Portable Tip Dresser for Spot Welding

2
MOQ
260
Precio
24V Lithium Battery Brushless Motor Electrode Cap Grinder Single Side Portable Tip Dresser for Spot Welding
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Información básica
Lugar de origen: Porcelana
Nombre de la marca: BLM
Pago y Envío Términos
Detalles de empaquetado: Caja 1PC/1
Tiempo de entrega: 7-20 días laborables
Condiciones de pago: T/T
Descripción de producto
24V Lithium Battery Brushless Motor Electrode Cap Grinder
24V Lithium Battery Brushless Motor Electrode Cap Grinder Single Side Portable Tip Dresser for Spot Welding 0
Product Name Single Side Electric Tip Dresser
Power Source Lithium Battery Power Supply
Grinding Maximum Diameter 18mm (matched according to the tool holder)
Speed 1600 r/min
Battery Capacity 24V - 10A
Weight 2.35kg
BLM lithium battery brushless electrode cap grinder is a professional portable single side tip dresser designed for fast and precise repairing of spot welding electrode caps. Powered by a 24V large capacity lithium battery, this cordless grinder delivers excellent mobility and convenience for on-site welding maintenance.
Built with a high-performance brushless motor, the electrode grinder features stable rotation, low noise, low heat generation and long service life, greatly improving working efficiency compared with traditional manual or brushed motor grinders. The single side grinding structure ensures fast and accurate dressing of electrode caps, restoring the electrode tip to standard shape and size, which effectively improves welding quality, reduces spatter and prolongs electrode life.
This portable tip dresser supports grinding for electrode caps up to 18mm in diameter, compatible with most standard welding electrodes in the global industry. With compact design, light weight and easy operation, it is widely used in automotive manufacturing, home appliance production, sheet metal fabrication, hardware processing and other resistance welding applications.
We provide customizable cutter and holder options to meet different electrode types and working requirements. Each electrode cap grinder is strictly tested before delivery to ensure stable performance and long durability.
24V Lithium Battery Brushless Motor Electrode Cap Grinder Single Side Portable Tip Dresser for Spot Welding 1
Usage Instructions
  1. Install the lithium battery to the tail end of the grinder
  2. Insert one side of the blade into the hole on the wall of the tool box
  3. Place the knife box with the installed blade on the rotating gear
  4. Check the direction of the knife box and align it with the electrode head
  5. Set the required power and speed for the tail switch
  6. After the blade contacts the electrode head, manually press the bottom control grinding button
  7. Apply pressure within the range of rotation during grinding
24V Lithium Battery Brushless Motor Electrode Cap Grinder Single Side Portable Tip Dresser for Spot Welding 2
Frequently Asked Questions
What's the power supply?
It uses 24V 10Ah rechargeable lithium battery, cordless design.
Can you customize the cutter?
Yes, we accept customized cutters for different electrodes.
What's the max grinding diameter?
Max 18mm, depends on the tool holder.
What's the warranty?
12 months after shipment.
What's MOQ and delivery time?
MOQ: 2pcs; Delivery: 7-20 working days.
